Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning

Shenzhen Hanwei Laser Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning from wholesalers

    Buy cheap Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning from wholesalers
    • Buy cheap Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning from wholesalers
    • Buy cheap Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning from wholesalers
    • Buy cheap Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning from wholesalers

    Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning

    Ask Lasest Price
    Brand Name : HanWei
    Model Number : HW-20-60150
    Certification : CE
    Price : USD / Set
    Payment Terms : T/T
    Supply Ability : 2000 Sets / year
    Delivery Time : 10 working days
    • Product Details
    • Company Profile

    Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning

    Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning


    Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning Description:


    The Handheld Single - Motor Triple - Function Apparatus marks a substantial advancement within the domain of portable multi - purpose tools. Propelled by a solitary but robust motor, this device integrates three crucial functions: welding, cutting, and cleaning. All these functions are neatly incorporated into an ergonomically designed and sleek handheld casing.
    Regarding welding, it meticulously regulates the amperage and voltage to produce a steady arc. This allows for robust and precise welds on diverse materials such as steel, stainless steel, and aluminum. For cutting operations, a concentrated high - intensity beam pierces materials of varying thicknesses at modifiable speeds and depths, guaranteeing neat and efficient cuts. In the cleaning mode, it sucks in cleaning agents or water and converts them into a potent, adjustable high - pressure spray through a flexible nozzle. This effectively eradicates rust, dirt, and pollutants. This apparatus showcases remarkable adaptability and is appropriate for a broad spectrum of settings, including workshops, construction areas, and industrial maintenance sites, performing admirably in all three key functions.
    .

    Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning Features:

    • Product Name: Fiber Laser Three-in-One Machine
    • Handheld Laser Gun Weight: 0.7kg
    • Laser Power: Up to 3000W for welding and 2000W for cleaning
    • Standard Focus length: 60 and 150mm standard Focus length adjustable
    • Welding Laser Beam Size: 0-5mm Adjustable
    • Cleaning Laser Beam Size: 0-50mm Adjustable
    • Laser Head Connection: QBH
    • Laser Beam Form: Line “一”
    • Welding Materials: Steel / Stainless Steel / Aluminum
    • Cooling method: Water Cooling
    • Gas: Argon / Nitrogen

    The Handheld Single - Motor Three - Function Device stands out as an excellent choice for metalworking, machinery repair, and surface pre - treatment in workshops and manufacturing plants. It utilizes a maximum power of 3000W for welding and 2000W for cleaning, which allows it to handle steel, stainless - steel, and aluminum materials. The laser beam is in a linear shape and is connected through a QBH interface, and it requires the use of argon or nitrogen gas.
    This handheld laser device, weighing 0.7 kilograms, comes with an adjustable standard focal length that spans from 60 to 150mm. Moreover, it provides adjustable laser beam diameters for both the welding and cutting procedures. The diameter of the welding beam can be adjusted within the range of 0 to 5mm, while the cleaning beam diameter can be varied from 0 to 50mm. To guarantee effective heat dissipation during its operation, the machine makes use of a water - cooling system. This helps in maintaining stable performance and extending its service life.

    Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning Technical Parameters:


    Product Name

    Handheld Single Motor Three-in-One Machine

    Laser Power

    Up to 3000W for welding and 2000W for cleaning

    Handheld Laser Gun Weight

    0.7 KG

    Cleaning Beam Form

    Line " 一 "

    Standard Focus length

    60 and 150mm standard Focus length adjustable

    Wire Feeding Device

    Standard type : 0.8&1.0&1.2&1.6mm wire

    Double Route Wire Feeder

    Option (Same time double route feeding)

    Welding Laser Beam Size

    0-5mm Adjustable

    Cleaning Laser Beam Size

    0-50mm Adjustable

    Fiber Connector

    QBH

    Adopt Laser Source

    1064~1080nm Fiber laser source

    Welding Parameter Save

    30 kinds of different welding parameter save



    Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning Application Advantages:

    The HanWei HW - 20 - 60150 Handheld Single - Wobble Triple - Function Machine demonstrates outstanding application benefits. Its remarkable portability, attributed to its compact and lightweight build, makes it ideal for use in restricted areas and mobile tasks. This boosts operational agility without relying on elaborate machinery or a large labor force.
    This apparatus combines welding, cutting, and cleaning capabilities. In welding, boasting a 3000W power output, it performs exceptionally well when joining steel, stainless steel, and aluminum. The welding beam, which can be adjusted from 0 to 5mm, is capable of fulfilling various welding demands. Concerning the cutting function, the laser beam can slice through materials with adjustable cutting velocity and depth. As for the cleaning function, with a 2000W power, the beam, adjustable from 0 to 50mm, is highly effective in cleaning a wide array of surfaces and is suitable for automotive, domestic, and industrial equipment cleaning.
    It is energy - saving and cost - efficient. The single - motor setup conserves energy, simplifies work procedures, and cuts down on both time and energy usage. Its uncomplicated structure leads to reductions in production and maintenance expenses. Additionally, it is user - oriented, as it doesn't necessitate specialized instruction, is accessible to a wide range of users, and helps to minimize mistakes and training - associated costs.

    Handheld 3-in-1 Laser Welding Machine for Welding / Cutting and Cleaning Packing:

    • Seven kinds of nozzles
    • A set of Connection Cables and Line
    • Two Protective Lens
    • One 15v Power Supply
    • One Handheld Laser Head
    • One Controller
    • One Touch Screen Monitor
    • One Focus Lens for cleaning
    • One Safety Switch Clip
    • One Wire feeding device
    • One User Manual


    Shen Zhen HanWei Laser Enterprise and Feature:


    Shenzhen Hanwei Laser Equipment Co., Ltd. is committed to providing all global integrators with excellent welding technology. As a national high - tech and newly - recognized specialized enterprise, it focuses on the research, development, manufacturing, and sales of a comprehensive industrial chain that includes welding lasers, laser control systems, laser optical systems, and laser welding processes. The company's product lineup comprises nine major series of laser welding machines, such as the AMB Spot Ring Spot Welding Machine, Blue Light Welding Machine, along with their relevant supplementary components.
    Hanwei Laser follows the business tenet of "prioritizing R&D, backed by technology, and protected by service" to serve B - end clients. It has a capable team boasting extensive knowledge and experience in laser welding and related areas. The products are widely applied in various sectors, including new energy batteries, automotive, electronics, and household appliances, demonstrating distinct welding capabilities. Significantly, the company has made remarkable technological advancements. The AMB Spot Ring Spot + Blue Light Composite Swing Welding Machine represents a world - leading innovation, solving the problems in welding highly reflective materials. Other models like the AMB Spot Ring Spot + Semiconductor Composite Welding Machine and the Semiconductor + Single Lamp Single Rod 600W Composite Laser Welding Machine have also efficiently addressed specific welding problems in the power battery field.
