High Laser Absorptivity Blue Laser Beam Industrial Laser Welding
Machine High Performance
Product Description:
Industrial Laser Welding Machine HW-B Blue Laser
HANWEI laser has started to research and develop Blue-laser almost
at the same time with laser welding enterprise in Europe, America
and Japan.
Use independent R&D blue laser system to create new laser
welding fields (Blue laser source, Blue- laser control system, Many
kinds of multiple special purpose of blue welding head).
Mainly used for copper welding, silver welding, gold welding and
other High reflectivity materials welding. The Blue laser with
incomparable super high absorptivity (The high reflectivity
materials in Blue-laser wave range with more than 60%
absorptivity).
Widely used in new energy industry, semiconductor industry.
Features:
The Blue laser with greatest advantages in High reflectivity
materials welding: Welding process with Low spatter, High
stability, High welding effect and quality, One-side welding with
back side formation advantages.
Technical Parameters:
Blue Laser Source
| Model | HW-B-50W | HW-B-100W | HW-B-200W | HW-B-500W | HW-B-1000W |
| Laser Power | 50 W | 100 W | 200 W | 500 W | 1000 W |
| Wavelength | 445 nm | 445 nm | 445 nm | 445 nm | 445 nm |
| Output power | 50 W | 100 W | 200 W | 500 W | 1000 W |
| Power stability | ± 0.5 % | ± 0.5 % | ± 0.5 % | ± 0.5 % | ± 0.5 % |
| Cooling way | Air | Water | Water | Water | Water |
| Equipment power | 250 W | 1000 W | 2000 W | 4000 W | 5000 W |
| Pulse width | 0.5~CW | 0.5~CW | 0.5~CW | 0.5~CW | 0.5~CW |
Laser Welding Head
| Welding head Model | HW-36-T-D80 | HW-36-T-QBH |
| Usable Power | 50 - 200 W | ≥500 W Minimum |
| Collimating length | 70 | 70 |
| Focus length | 70 / 150 | 70 / 150 |
| Interface type | D80 | QBH |
| Accessible wave range | 1064 | 1064 |
| Head Type | T | T |
| Net weight | 1.1 kg | 2.5 kg |
| Usable laser source | Blue laser | Blue laser |
Applications:
Mainly used for copper welding, silver welding, gold welding and
other High reflectivity materials welding. The Blue laser with
incomparable super high absorptivity (The high reflectivity
materials in Blue-laser wave range with more than 60%
absorptivity).
Widely used in new energy industry, semiconductor industry.
Customization:
Customized Industrial Laser Welding Machine
Our industrial laser welding machine, HanWei HW-I, is a superior product for your laser welding needs. With its
origin from Shenzhen, China, this machine is highly automated and
provides fast welding speed. It is highly portable and of moderate
cost, making it a great choice for industrial welding needs.
This machine is ideal for 18650 battery laser welding needs. Its
advanced features make it suitable for fast, reliable, and
efficient welding.
Support and Services:
Handheld Welding Head Technical Support and Service
We provide technical support and service to customers using our
Handheld Welding Head products. Our support staff is available to
answer any questions about the product, provide troubleshooting
advice, and help with product installation and maintenance. We also
offer extended warranties and replacement parts for our Handheld
Welding Head products.
- Troubleshooting and repair
- Software updates and upgrades
- Performance optimization and maintenance
- Replacement parts
- User training and education
If you have any questions or need assistance with our Handheld
Welding Head products, please contact us.
HanWei Laser already have been shipped and served lot's of over
customers in various countries all of the world. Have dealers and
agent in all of the world. Support on line remote technical support
in time and local agent technical support.
Packing and Shipping:
Packaging and Shipping
The Handheld Welding Head is packaged in a paper box ,wooden frame
or plywood, secured with packaging foam. The box is then labeled
with the product name, size, and shipping address. The product is
then shipped through a third-party shipping service.
HanWei Laser already have been shipped and served lot's of over
customers in various countries all of the world.
FAQ:
- Q. What is the Brand Name of this Industrial Laser Welding Machine?
- A. The Brand Name of this Industrial Laser Welding Machine is
HanWei.
- Q. What is the Model Number of this Industrial Laser Welding
Machine?
- A. The Model Number of this Industrial Laser Welding Machine is
HW-I.
- Q. Where is this Industrial Laser Welding Machine made?
- A. This Industrial Laser Welding Machine is made in Shenzhen,
China.
- Q. Does this Industrial Laser Welding Machine have a warranty?
- A. Yes, this Industrial Laser Welding Machine has a warranty.
Please contact our customer service staff for details.
- Q. What is the weight of this Industrial Laser Welding Machine?
- A. The weight of this Industrial Laser Welding Machine is
approximately 70kg.
HanWei Laser Company Profile
Hanwei Laser Equipment Co.,Ltd is a leading corporation of laser
welding systems for a variety of industries, is the worldwide
innovation leader in the development of components and system
solutions in the field of laser welding technology, including
automobile battery, new energy resources, energy storages,
aerospace, jewelry, metal processing, medical, plastic, and more.
Hanwei laser Founded in 2016, the company has over two decades of
experience in the industry and utilizes the latest technology to
provide innovative, reliable, and high-quality laser solutions.
Great changes are driven by technology. And technologies change the
world.
The company offers a range of laser systems, including desktop and
handheld laser system models, that use advanced fiber, pulsed or
continuous wave, blue laser, diode laser, hybrid laser technology
to meet the exact needs of their customers. Also provide custom
solutions for specialized applications and offer training and
support to help their customers get the most out of their laser
systems.
Hanwei Laser has a global presence with offices and distributors in
Europe, North America, Asia, and Middle East, making it accessible
to customers all over the world.
The company has a reputation for excellent customer service,
quality products, and innovative solutions, which have made it a
trusted name in the laser welding industry.
