Industrial Laser Welding Machinery Hybrid Blue Laser And Fiber
Laser For Copper Brass Welding
Product Description:
Industrial Laser Welding Machine HW-B Blue Laser
Blue laser (450nm) and fiber laser (1064nm) Hybrid-laser wobble
welding can achieve blue laser source and fiber laser source
coaxial recombination. It is used in thick and highly reflective
metal welding (gold, silver, copper, aluminum). By wobble method
make itself used more widely and technical parameter. The
reflective materials have more highly absorptivity for blue-fiber
hybrid laser make less spark in welding process and achieve quality
welding and nice welding surface.
Widely used in new energy industry, semiconductor industry.
More than 70% high absorptivity. Reduce much more equipment power
than red guide beam laser to reduce cost.
Suitable for thick and highly reflective material welding.
During welding with low spark, high and stable welding quality.
Achieve deep penetration and smooth welding surface.
Mainly used for copper welding, silver welding, gold welding and
other High reflectivity materials welding. The Blue laser with
incomparable super high absorptivity (The high reflectivity
materials in Blue-laser wave range with more than 60%
absorptivity).
Widely used in new energy industry, semiconductor industry.
Features:
1.More than 70% high absorptivity. Reduce much more equipment power
than red guide beam laser to reduce cost.
2.Suitable for thick and highly reflective material welding.
3.During welding with low spark, high and stable welding quality.
Achieve deep penetration and smooth welding surface.
Technical Parameters:
| Name | Parameter |
|---|
| Product Name | Blue and Fiber laser Hybrid Laser Welding Machine |
| Laser Source | Blue Laser Source and Fiber Laser Source. |
| Wavelength | 445nm+1064nm |
| Laser Power | Customized |
| Laser Work Mode | HanWei Laser Control Mode |
| Cooling System | Water Chiller Cooling. |
| Connection Port | QBH and D80 |
| Head Type | Y |
| Machine Weight | 350 Kg. |
| Safety Switch | Yes |
Laser Welding Head
| Welding head Model | HW-36-T-D80 | HW-36-T-QBH |
| Usable Power | 50 - 200 W | ≥500 W Minimum |
| Collimating length | 70 | 70 |
| Focus length | 70 / 150 | 70 / 150 |
| Interface type | D80 | QBH |
| Accessible wave range | 1064 | 1064 |
| Head Type | T | T |
| Net weight | 1.1 kg | 2.5 kg |
| Usable laser source | Blue laser | Blue laser |
Applications:
Mainly used for copper welding, silver welding, gold welding and
other High reflectivity materials welding. The Blue laser with
incomparable super high absorptivity (The high reflectivity
materials in Blue-laser wave range with more than 60%
absorptivity).
Widely used in new energy industry, semiconductor industry.
Customization:
Customized Industrial Laser Welding Machine
Our industrial laser welding machine, HanWei HW-I, is a superior product for your laser welding needs. With its
origin from Shenzhen, China, this machine is highly automated and
provides fast welding speed. It is highly portable and of moderate
cost, making it a great choice for industrial welding needs.
This machine is ideal for 18650 battery laser welding needs. Its
advanced features make it suitable for fast, reliable, and
efficient welding.
Support and Services:
Handheld Welding Head Technical Support and Service
We provide technical support and service to customers using our
Handheld Welding Head products. Our support staff is available to
answer any questions about the product, provide troubleshooting
advice, and help with product installation and maintenance. We also
offer extended warranties and replacement parts for our Handheld
Welding Head products.
- Troubleshooting and repair
- Software updates and upgrades
- Performance optimization and maintenance
- Replacement parts
- User training and education
If you have any questions or need assistance with our Handheld
Welding Head products, please contact us.
HanWei Laser already have been shipped and served lot's of over
customers in various countries all of the world. Have dealers and
agent in all of the world. Support on line remote technical support
in time and local agent technical support.
Packing and Shipping:
Packaging and Shipping
The Handheld Welding Head is packaged in a paper box ,wooden frame
or plywood, secured with packaging foam. The box is then labeled
with the product name, size, and shipping address. The product is
then shipped through a third-party shipping service.
HanWei Laser already have been shipped and served lot's of over
customers in various countries all of the world.
FAQ:
- Q. What is the Brand Name of this Industrial Laser Welding Machine?
- A. The Brand Name of this Industrial Laser Welding Machine is
HanWei.
- Q. What is the Model Number of this Industrial Laser Welding
Machine?
- A. The Model Number of this Industrial Laser Welding Machine is
HW-I.
- Q. Where is this Industrial Laser Welding Machine made?
- A. This Industrial Laser Welding Machine is made in Shenzhen,
China.
- Q. Does this Industrial Laser Welding Machine have a warranty?
- A. Yes, this Industrial Laser Welding Machine has a warranty.
Please contact our customer service staff for details.
- Q. What is the weight of this Industrial Laser Welding Machine?
- A. The weight of this Industrial Laser Welding Machine is
approximately 70kg.
