80w YAG Laser Welding Machine For 0.6mm 0.8mm 1mm Thin Stainless
Steel Welding For Phone Accessories
Product Description:
YAG Laser Welding Machine Serial Description:
The YAG Laser Welding Machine is an advanced and efficient welding
tool developed for battery cell ear welding and electrical
appliance welding. It adopts YAG laser source and pulse work mode,
and is suitable for welding in 5 to 45 temperature and clean
environment. The YAG Laser Welding Machine comes with an input
power of AC220v or AC380v and 50/60 Hz. Its model is HW-Y. This
machine allows for precise and reliable welding of battery cell
ears and electrical appliances, ensuring a high quality weld.
This machine has a wide range of applications, suitable for welding
of stainless steel, copper, aluminum, nickel and other metal
materials. It is ideal for welding of various products in
industries such as automotive, electronic, medical, communication,
and aerospace. With its high precision design and reliable
performance, it is widely used for welding of battery cells and
electrical appliances.
The YAG Laser Welding Machine is highly reliable and efficient. It
is easy to operate and maintain. It is an ideal choice for battery
cell ear welding and electrical appliance welding.
HW-YAG-80W:
The product adopt fiber conducted output, multi-optical path
output, can be match different worktable. Unique optical system
design with import quartz optical lens, overseas coating
technology, high anti-injury threshold value, light speed stable,
matching with our independent R&D PID self-adaptation power
feed-back system power supply.
Optical communication, USB connector, 18650 phone battery cover,
battery tab-lead. Connector.Hardware, kitchen, jewelry, elevator
panel, household electrical appliances, corrugated pipe, battery,
Solar energy, Optical communication cover, aviation parts.
YAG Welding Head :
YAG welding head use for 8W-600W YAG laser source, the product with
small size, light weight, (T, F, Y) three types suitable for
different structures. Inside of welding head is completely sealed,
can avoid optical parts from dust pollution. Adopt gas curtain
parts, reduce the welding smoke and splash residue to pollute lens.
It is high economic and efficiency welding head.
Features:
1. Adopt fiber conducted output, realize energy separate light,
time separate light.
2. Integrate independent R&D PID power feed-back technology,
realize keep same welding effective.
3. Unique optical design, import optical lens, high anti-injury
threshold value, light speed stable.
Technical Parameters:
| Features | Value |
|---|
| Product Name | YAG Laser Metal Laser Welding Machine |
| Model | HW-Y-80 |
| Input Voltage | AC380v 50/60 Hz |
| Wavelength | 1064nm |
| Output Power | 80w |
| Max Pulse Energy | 50J |
| Max Peak Power | 5 Kw |
| Optical Route | 1 - 4 Optional |
| Net Weight | 170 Kg |
| Pulse Width | 15ms |
| Repeat Frequency | 100 Hz |
| Power Stability | +- 2.5%. |
| Working Mode | Pulse |
| Cooling Method | Internal Mini Water Chiller Cooling |
| Equipment Power | 3 Kw |
| Optical Separate Type | Energy / Timing |
| Dimension | 1175*515*980 mm |
Applications:
Laser welding can be applied to the welding of various metals,
alloys, steel and other alloy materials, as well as to the welding
of various dissimilar metals such as copper brass, copper titanium,
nickel copper, and copper titanium.
Automotive parts industry: engine cylinder gasket; Hydraulic tappet
sealing welding; Filter sealing welding; Spark plug welding;
Welding of valve push rod; Sealing welding of anti-collision airbag
electric detonator; Heat treatment of crankshaft or cylinder liner;
and so on
Electronics industry: Sealing welding of the shell of mobile phone
batteries and power batteries; Solid state relay sealing welding;
Welding of connector data cables; and so on
Hardware industry: tools, accessories, tableware, lighting
fixtures; and so on.
The product adopt fiber conducted output, multi-optical path
output, can be match different worktable. Unique optical system
design with import quartz optical lens, overseas coating
technology, high anti-injury threshold value, light speed stable,
matching with our independent R&D PID self-adaptation power
feed-back system power supply.
Optical communication, USB connector, 18650 phone battery cover,
battery tab-lead. Connector.Hardware, kitchen, jewelry, elevator
panel, household electrical appliances, corrugated pipe, battery,
Solar energy, Optical communication cover, aviation parts.
Support and Services:
HWTechnical Support and Service
We provide technical support and service to customers using our
Handheld Welding Head products. Our support staff is available to
answer any questions about the product, provide troubleshooting
advice, and help with product installation and maintenance. We also
offer extended warranties and replacement parts for our Handheld
Welding Head products.
- Troubleshooting and repair
- Software updates and upgrades
- Performance optimization and maintenance
- Replacement parts
- User training and education
If you have any questions or need assistance with our Handheld
Welding Head products, please contact us.
HanWei Laser already have been shipped and served lot's of over
customers in various countries all of the world. Have dealers and
agent in all of the world. Support on line remote technical support
in time and local agent technical support.
Packing and Shipping:
The Welding Head is packaged in a paper box ,wooden frame or
plywood, secured with packaging foam. The box is then labeled with
the product name, size, and shipping address. The product is then
shipped through a third-party shipping service.
HanWei Laser already have been shipped and served lot's of over
customers in various countries all of the world.
FAQ:
- Q1: What is a YAG Laser Welding Machine?
- A: YAG Laser Welding Machine, produced by HanWei, model HW-Y, is a
machine that uses a laser beam to melt two or more metals together
in order to create a permanent bond. It is often used in the
production of jewelry and watches. It is made in Shenzhen, China.
- Q2: What are the advantages of YAG Laser Welding Machine?
- A: YAG Laser Welding Machine is known for its accuracy and
precision, as well as its ability to weld materials that would
otherwise be difficult to join. It is also known for its high-speed
operation and low heat input, making it ideal for use in a variety
of industries.
- Q3: What materials can be welded by YAG Laser Welding Machine?
- A: YAG Laser Welding Machine is suitable for welding a variety of
materials, including stainless steel, aluminum, brass, copper,
titanium, and tungsten. It is also suitable for welding metals with
different thicknesses.
- Q4: What is the welding depth and width of YAG Laser Welding
Machine?
- A: The welding depth and width of YAG Laser Welding Machine depend
on the material and thickness of the materials being welded.
Generally, the maximum welding depth is 0.5 mm and the maximum
welding width is 1 mm.
- Q5: What is the output power of YAG Laser Welding Machine?
- A: The output power of YAG Laser Welding Machine ranges from 500W
to 2000W, depending on the model and application.
