    400Hz Handheld Welding Head , Fiber Laser Head With Wire Steel Aluminum

    Ask Lasest Price
    Brand Name : HanWei
    Model Number : HW-20-60150
    Certification : CE, FDA
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 6000 Set per year
    Delivery Time : 5 work days
    • Product Details
    • Company Profile

    400Hz Handheld Welding Head , Fiber Laser Head With Wire Steel Aluminum

    Metal Welding Instrument Handheld Laser Head Welding Wire Steel And Aluminum

    Handheld Welding Head Single Motor Handheld Welding Description:

    Laser welding is a new and advanced welding method, it is one of important aspects in material processing technology application.

    The single motor wobble handheld welding is new welding type of laser welding field, the laser beam can be swing by motor lens to form more widely welding width and depth.The working principle is : Through the swing beam to reform output laser beam shape to get the output beam size more bigger and more stronger penetrating power.

    The Handheld Welding Head single motor wobble type of Fiber Laser Welding Machine is exclusively designed and manufactured by HanWei Laser.

    The company HanWei Laser Equipment Co.,Ltd is one of the only a few supplier around the world, who can research and develop,manufacturing the whole set of handheld laser welding machine : Handheld welding head → Laser control system → Wobble control system → Wire Feeding device→ Laser Source.

    HanWei Laser develops and manufactures main part of laser welding machine such as laser control system, laser welding head. and also provides detail accessories and whole laser welding solution for customers : From consumable parts such as protective lens, nozzle to automatic and robot laser welding solution :


    Handheld Welding Head Specification:
    Product NameHandheld Welding Head
    Usable Laser Power1000W-3000W
    Laser SourceFiber Laser Source
    Interface typeQBH
    Accessible wave range1064 nm
    Net weight0.7 kg
    Laser head size216*287 mm
    Laser head packing size39*22*29cm.
    Laser head packing gross weight9kg
    Standard single route wire feeding device packing Info17Kg. 70*40*65cm.
    Double route wire feeding device packing Info30Kg. 79*45*70cm.
    Usable laser sourceMost of laser source
    Handheld Welding Head Features and Advantages:
    *Extremely Light in weight and small volume,adopt streamline ergonomic design make holding operation is comfortable.
    *The control system is very easy and requires little prior knowledge on the part of the operator.
    *With safety lock function to ensure safety process.
    *Internal structure of welding head with extremely simple design, easy to operate and maintenance.
    *Adjustable Laser beam range: 0.5 - 5 mm.
    *Support standard single route wire feeding.
    *Support Dual route wire same time feeding, welding bead up to 12mm. And also can switch any one route to use as single route wire feeding.
    *Laser beam scan mode: Various shape.
    *Supply Four welding modes (CW – Continue, Adjust laser out frequency, Argon weld type, QCW mode peak power output).
    *Independent Research and Develop all products:Laser head, Control system, Wire Feeding device. Safety lock.
    *Digital setting parameters in welding machine interface.
    *Support different languages.
    *All performance features can be customized to meet individual customer requirements.

    Handheld Welding Head Product Show:


    Laser Welding Head. Extremely Light in weight and small volume,adopt streamline ergonomic design make holding operation is comfortable.


    Control System : Torch monitor. The control system is very easy and requires little prior knowledge on the part of the operator.



    Laser welding head, control system, monitor, power supply and spare parts. With safety lock function to ensure safety process.


    Standard single route wire feeding device


    Dual route wire feeding device. Support Dual route wire same time feeding, welding bead up to 12mm. And also can switch any one route to use as single route wire feeding.


    Paper Box Packing


    Welding Sample Show


    Nozzle


    Lens and Mirrors : Protective lens, Focus lens, Motor lens, Collimating lens.
